Lisun LPCE-2(LMS-9000BUV) UV Lamp Testing System (200-400nm)

Lisun LPCE-2(LMS-9000BUV) UV Lamp Testing System (200-400nm)

The Lisun LPCE-2 (LMS-9000BUV) UV Lamp Testing System is an optimal industrial solution designed to simultaneously measure and analyze spectral parameters, radiation power, peak wavelength, and electrical characteristics of various UV lamps (in the 200-400nm wavelength range). The device operates based on advanced spectroscopic analysis methods combined with an integrating sphere, helping to thoroughly test the quality and performance of lamps without damaging or affecting the sample.

Outstanding Features

Comprehensive UV spectral measurement system: The device is equipped with a high-precision CCD spectrometer specialized for the ultraviolet waveband (200-400nm) combined with an integrating sphere coated with a special reflective material, ensuring absolute accurate collection and analysis of UV radiation throughout the testing process.

Powerful parameter testing performance: Applying advanced optical signal processing technology, the system has the ability to quickly measure quantities such as radiant flux (mW), UV illuminance, center wavelength, and emission spectrum, achieving extremely high evaluation efficiency for UV lamp quality before putting products into the market or practical application.

Intelligent operation and connection system:

Flexible device connection interface: Helps synchronize data between the standard power source, spectrometer, and integrating sphere smoothly, ensuring the stability of measurement signals.

Combined data processing system: Integrates specialized computer software supporting recording, automatic calculation, drawing spectrum distribution charts, and quickly exporting test result reports.

Manufacturing materials and durable structure: The entire chamber frame and optoelectronic components use high-grade materials resistant to high-intensity ultraviolet rays, helping to maintain stability in long-term working environments, protecting equipment safety, and ensuring long-term accuracy.

Advanced safety operation mechanism: The system is designed according to optical laboratory safety standards, integrating circuit protection and radiation shielding features, ensuring stable operation in research laboratories and continuous production factories.

System Includes

1. LMS-9000BUV High Precision UV Spectroradiometer:

• Wavelength spectral range: 200-400nm (UV)

• Wavelength spectral accuracy: ±0.5nm (UV)

• Integration time: 0.1mS-60S

• Stray light: <0.015% (600nm), <0.03% (435nm)

• Chromaticity Coordinate Accuracy (Δx, Δy): ±0.0015, ±0.0005 (under standard lamp)

• Photometric linearity: ±0.3%

2. CFS-1.2M silica fiber

3. CASE-UV036 UV testing dark chamber

4. SLS-UV standard UV lamp source with calibration current (optional)

Technical Specifications:

• Pre-heating voltage: 2.5V

• Pre-heating current: 4A

• Starting voltage: 350 (V)

• Lamp current: 300mA

• 190~400nm

Practical Applications

In addition to its main function of testing germicidal UV lamp parameters, the Lisun LPCE-2 (LMS-9000BUV) is also widely applied in many other industries due to its high flexibility:

• UV Lamp & Sterilization Equipment Manufacturing Industry: Testing spectral quality and radiation power of UV-C and UV-B bulbs used in air, water, and surface disinfection.
• Healthcare & Food Industry: Evaluating the performance of ultraviolet lamp systems used in cleanrooms, hospitals, and food packaging sterilization lines.
• Laboratories & Research Institutes: Serving measurement work, research on the optical characteristics of materials, and specialized ultraviolet light sources.
