Lisun XD-80LS Water-Cooled Xenon Arc Aging Test Chamber (80℃, 98%RH, 290~800nm)
Contact
SKU: XD-80LS
Warranty: 12 Months
Origin: China
Product Details
<h2><strong>Lisun XD-80LS Water-Cooled Xenon Arc Aging Test Chamber (80℃, 98%RH, 290~800nm)</strong></h2>
<strong>The Lisun XD-80LS water-cooled Xenon arc aging test chamber</strong> is an optimal industrial solution designed to simulate the effects of full-spectrum sunlight (290~800nm), high temperature (up to 80℃), high humidity (up to 98% RH) combined with a water-cooling system to evaluate the resistance to aging, fading, or material transformation of test samples. The device operates based on high-grade accelerated environmental simulation methods, thoroughly testing durability indicators without damaging or affecting the basic structure of the sample other than for aging purposes.
<a href=”https://maydomau.vn/wp-content/uploads/2026/08/buong-kiem-tra-tuoi-tho-den-xenon-lisun-xd-80ls-xenon-lam-mat-bang-nuoc-80℃-98rh-290800nm-1.png”><img class=”wp-image-4629 size-full aligncenter” src=”https://maydomau.vn/wp-content/uploads/2026/08/buong-kiem-tra-tuoi-tho-den-xenon-lisun-xd-80ls-xenon-lam-mat-bang-nuoc-80℃-98rh-290800nm-1.png” alt=”” width=”800″ height=”800″ /></a>
<h2><strong>Technical Specifications:</strong></h2>
Working dimensions: 800*800*800mm
Temperature range: RT+10℃～80℃ (Adjustable)
Temperature error: ±2℃; Temperature variation: ±0.5℃
Humidity range: 65%-98% RH; Humidity variation: ±3%
Wind speed: ≤1.5m/s; Sample rack speed: 5-12r/min (Customizable)
Rainfall time: 0～9999min (Customizable)
Xenon lamp source: Water-cooled lamp
Number of Xenon lamps: 1 pc
Xenon lamp power: 6000W
Distance between sample rack and lamps: 200~375mm
Illumination time: 1～9999h, m, s continuous customization
Temperature control device integrates a high-precision microcomputer controller; Accuracy: 1℃ (Display range)
Resolution: ±0.1℃
Temperature sensor: PT100 platinum resistance thermometer
Control method: Temperature and humidity balanced thermal control
Temperature and thermal adjustment use P.I.D + S.S.R and combined channel control
Characteristics: Climatic patterns such as light, rain, temperature, humidity, wind, etc.
Xenon lamp irradiance: 550W/m²; Wavelength: 290~800nm
<a href=”https://maydomau.vn/wp-content/uploads/2026/08/buong-kiem-tra-tuoi-tho-den-xenon-lisun-xd-150lf-xenon-lam-mat-bang-khong-khi.png”><img class=”wp-image-4621 size-full aligncenter” src=”https://maydomau.vn/wp-content/uploads/2026/08/buong-kiem-tra-tuoi-tho-den-xenon-lisun-xd-150lf-xenon-lam-mat-bang-khong-khi.png” alt=”” width=”800″ height=”800″ /></a>
<h2><strong>Outstanding Features</strong></h2>
<strong>Comprehensive Xenon irradiation system:</strong> The device is equipped with a specialized water-cooled Xenon arc lamp with a wide spectral range from 290 to 800nm, ensuring the precise simulation of the full-spectrum sunlight waveband throughout the testing process.
<strong>Powerful aging test performance:</strong> Applying advanced radiation processing and environmental control technology, the system has the ability to rapidly accelerate material aging under harsh temperature and humidity conditions, achieving extremely high evaluation efficiency for weather resistance and durability before bringing products to market or practical application.
<strong>Intelligent operation and connection system:</strong>
<ul>
<li><strong>Flexible device connection interface:</strong> Helps synchronize data between the temperature, humidity control system (up to 80℃, 98% RH) and the Xenon light source smoothly, ensuring the stability of test parameters.</li>
<li><strong>Combined data processing system:</strong> Integrates a control screen and specialized software supporting recording, automatic calculation of irradiation cycles, and quickly exporting test result reports.</li>
</ul>
<strong>Manufacturing materials and durable structure:</strong> The entire machine housing and test chamber use high-grade anti-corrosion, moisture-resistant, and high-temperature-resistant materials, helping to maintain stability in harsh working environments, protecting equipment safety, and ensuring long-term accuracy.
<strong>Advanced safety operation mechanism:</strong> The system is designed according to modern safety technical standards, integrating over-temperature, over-current, water supply protection, and error warning features, ensuring stable operation in laboratories and continuous production factories.
<h2><strong>Practical Applications</strong></h2>
In addition to its main function of testing aging and weather durability for materials under high temperature and humidity conditions, the Lisun XD-80LS is also widely applied in many other industries due to its high flexibility:
<a href=”https://maydomau.vn/wp-content/uploads/2026/08/buong-kiem-tra-tuoi-tho-den-xenon-lisun-xd-80ls-xenon-lam-mat-bang-nuoc-80℃-98rh-290800nm.png”><img class=”wp-image-4630 size-full aligncenter” src=”https://maydomau.vn/wp-content/uploads/2026/08/buong-kiem-tra-tuoi-tho-den-xenon-lisun-xd-80ls-xenon-lam-mat-bang-nuoc-80℃-98rh-290800nm.png” alt=”” width=”800″ height=”800″ /></a>
<ul>
<li><strong>Plastics, Paint & Coating Industry:</strong> Testing the fading resistance, cracking, and aging of paints, plastic materials, and rubber under the combined action of Xenon light, high temperature, and high humidity.</li>
<li><strong>Textiles & Outdoor Materials Industry:</strong> Evaluating the color fastness of fabrics, artificial leather, and materials used in harsh tropical weather conditions.</li>
<li><strong>Laboratories & Quality Inspection:</strong> Serving research work, technical measurement, and periodic testing of material aging standards in specialized inspection centers.</li>
</ul>
