PCE-CSM-BAT Replacement Battery

PCE-CSM-BAT Replacement Battery

The PCE-CSM-BAT battery is a genuine rechargeable battery manufactured by PCE Instruments, specifically designed as a replacement power source for the company’s handheld colorimeters and spectrophotometers.

Key Features

• Stable performance: Ensures a consistently stable voltage supply for the optical system and sensors of the color meter, helping the device maintain high accuracy during every measurement.
• High durability and long lifespan: Supports a large charge-discharge cycle with minimal degradation over time, helping to extend the operating lifecycle of measuring devices in the laboratory or field.
• Easy replacement: Accurate connector design and standard dimensions allow users to quickly replace it themselves when the old battery capacity declines after prolonged use.

Compatible Device Models

The PCE-CSM-BAT battery code is used across popular handheld color meter models from the manufacturer, including:

• PCE-CSM 3
• PCE-CSM 6
• PCE-CSM 7
• PCE-CSM 8
• PCE-CSM 10

Basic Technical Specifications

• Product code (Model/Part Number): PCE-CSM-BAT (Compatible with component manufacturer code: BQ021).
• Battery type: High-quality Li-Polymer (Lithium-ion Polymer) battery, safe and effective against leakage.
• Rated voltage: 3.7 V.
• Capacity: 3,500 mAh (12.95 Wh), providing abundant energy for extended working sessions.
• Standard dimensions: Designed to fit completely and snugly into the device’s battery compartment (approx. 76.40 x 47.45 x 9.40 mm).
